首頁 > 產品中心 >粉塵清除機

粉塵清除機

Dust Collector

自動清除板材因砂光而殘留下來的粉塵，提高涂裝質量。
This machine automatically removes the dust left over from the plate due to sand light thus improving the coating quality.
產品亮點
Highlights
本機吸塵率高，特殊設計集塵罩，配置強力吹風機，可將磨砂粉塵全部收集于機內。
皮帶采用條紋系列，厚度3mm，輸送采用鋁合金外殼齒輪減速馬達，采用變頻器控制。
除塵進風采用喇叭口設計方式，強制除塵，引風口徑Φ90mm。

This machine has high dust absorption rate special design dust collection cover equipped with a strong hairdryer which can collect all the sand dust in the machine.
The belt adopts the stripe series the thickness is 3mm and the transmission adopts the aluminum alloy shell gear deceleration motor and the control adopts the frequency converter.
Dedusting into the wind adopts the horn mouth design method mandatory dedusting lead the air diameter is φ 90mm.

產品參數
Parameter
項目 Item 參數/Paramter
加工寬度 Working width 1300mm
加工厚度 Working thickness 3-80mm
輸送電機功率 Feeding motor power 0.75kw，變頻調速，Inverter
輸送皮帶規格 Conveyor belt specification 5080*1320*3mm
總功率 Total power 2.5kw
外形尺寸 Overall dimensions 2500*2200*1700mm
