首頁 > 產品中心 >自動送料機

自動送料機

Automatic Feeder

適用于板材，木地板等材料進料的工件輸送。
This machine automatically removes the dust left over from the plate due to sand light thus improving the coating quality.
產品亮點
Highlights
本主體機架采用高強度工業鋁型材40*160系列與3T冷板所焊接底架組裝而成。
主動輪軸承采用帶座外球面向心球系列型號SBLF206，被動輪軸承采用深溝球軸承系列型號6207。
皮帶采用菱形皮帶系列，輸送采用鋁合金外殼齒輪減速馬達，采用變頻器控制。

The main frame is assembled by welding underframe of high strength industrial aluminum 40*160 series and 3T cold plate.
The active wheel bearing USES SBLF206 with outer ball facing the center ball series and the passive wheel bearing USES roove ball series.
Dedusting into the wind adopts the horn mouth design method mandatory dedusting lead the air diameter is φ 90mm.


產品參數
Parameter
項目 Item 參數/Paramter
加工寬度 Working width 1300mm
加工厚度 Working thickness 3-30mm
輸送電機功率 Feeding motor power 1.5kw，變頻調速，Inverter
輸送皮帶規格
Conveyor belt specification
5150*1320*8.5mm
總功率 Total power 1.5kw
外形尺寸 Overall dimensions
2500*1720*1500mm
